Sampling Valves BioCheck Classic

By means of the BioCheck sampling valve, samples can be taken easily and safely out of closed systems like vessels and pipings. When designing this sterile fitting, special emphasis was placed on the aseptic, but also very compact design, so that the integration can be carried out easily and especially free from contamination in both sterile and in CIP/SIP cycles.


BioCheck sampling valves are certified to TA-Luft / VDI 2440 / VDI 3479

All housings are also available with only 1 outlet.
For all housings welding ends are the standard version, other connections on request.

Materialin contact with product
optional


not in contact with product
1.4404/AISI316L
1.4435/AISI316L
Hastelloy® C-22 and others
1.4301/AISI304

Gaskets
PTFE bellows
PTFE

Temperaturesmaximum PTFE
  continuous operation

steam sterilization
 		121 °C*

135 °C* short-time
(approx. 20 min)

Pressures closing pressure


air pressure
 		max. 10 bar
(others on request)

min 6 bar -
max. 10 bar
Surfaces
 in contact with product
optional


not in contact with product
Ra ≤ 0,8 µm
e-polished, other surfaces on request

Ra ≤ 1,6 µm

Connections
Standard-
pipe classes

DIN 11850-R2 (DIN 11866 A)
O.D.-Tube (DIN 11866 C)



S = self-closing lever
O = with lever for „open“ position
P = with bracket for prox. switch dm 12 mm
H = manual with hand wheel


Stroke

Standard DN 10 DIN = 3 mm
DN 15 DIN = 4,5 mm
Ingold version = 5 mm

          *dependent upon operating conditions
Request catalogue for more details.
  • solid stainless steel housing
  • complete separation from the environment
  • no dead , no sump , no dome, 100 % emptying
  • overhead installation possible
  • seal replacement without special tools
  • low downtime
  • long life ( > 1 million cycles , more on request)
  • contact with product 316L stainless steel, alternatively in Hastelloy® C-22 (2.4602) and other materials
On request.
All Valves are available in special alloys, such as Hastelloy® C-22, 1.4539/904L, 1.4529, AL-6XN® and others.
